Watertight Straight Connectors
Material
PA6 V-2 (Polyamide)
Fire Behaviour According to UL 94V-2
Thread
PG, Metric
Type
Straight
Temperature
-40°C to 100°C
Colour
Black
Protection
IP68
Features
High & active compression
Waterproof
Airtight
The claws and seals are of excellent design, can hold cable firmly and have a wider cable range.
The Powerful Watertight Fittings build with best tightening power and very high and active compression force to resist the ingress of high pressure water jet from any angle which can provide 100% dynamic waterproof and airtight performance over the widest range of corrugated tubings.The product can widely be applied to resist water impact or immersion as a tough cable protection system for any machines, devices and equipments with the very specific demands.
Specification of Watertight Connectors (PG)
